Industrial-grade 120 kVA on-line double-conversion three-phase UPS system. Delivers up to 96.5% operating efficiency, ultra-low input current distortion (THDi ≤ 3%), and unmatched power protection for enterprise data centres and large industrial facilities.
Contact us directly on WhatsApp to get the latest live rates & discounts.
The Riello Multi Sentry MST 120 is an advanced transformer-free online double-conversion UPS (VFI-SS-111) designed for heavy-duty applications. Perfect for large-scale data centres, telecommunications hubs, server farms, and complex industrial automated production plants, it offers robust protection against all power anomalies.
Equipped with a state-of-the-art IGBT rectifier and DSP (Digital Signal Processor) control, the MST 120 delivers an outstanding input power factor close to 1 with very low harmonic current distortion. This eliminates the need for expensive, bulky external filtering networks and guarantees complete compatibility with alternative generator systems. Its multi-level NPC inverter design scales up efficiency to 96.5% under normal operational conditions, reducing annual heat dissipation and operating costs.
Advanced Battery Care System: Protects battery life using flexible multi-level charging, automatic health testing, and temperature compensation.
Parallel Redundancy: Expandable ecosystem allowing up to 8 units to run concurrently for higher power capacity or system resilience.
Smart Operating Modes: Includes On-Line, Eco, Smart Active, Stand-by Off, and Frequency Converter modes.
Built-in Maintenance Bypass: Integrated manual and static bypass switches allow maintenance without killing power to the main load.
High-performance 30kVA / 24kW true online double-conversion 3-phase UPS with internal battery and digital signal processing (DSP) control.
| Rated Capacity | 120,000 VA / 108,000 W (0.9 Power Factor) |
|---|---|
| Technology | On-Line Double Conversion (VFI-SS-111) |
| Input Voltage | 380 / 400 / 415 V AC 3-Phase + Neutral |
| Input Frequency | 40 – 72 Hz |
| Input Current Distortion | THDi ≤ 3% |
| Input Power Factor | ≥ 0.99 |
| Output Voltage | 380 / 400 / 415 V AC 3-Phase + Neutral (selectable) |
| Output Frequency | 50 / 60 Hz selectable |
| Output Waveform | Pure Sinewave |
| Battery Configuration | ±240 V DC nominal system voltage |
| Protection Rating | IP20 |
High-performance 40kVA / 32kW true online double-conversion 3-phase UPS with internal battery and digital signal processing (DSP) control.
High-performance 60kVA / 48kW true online double-conversion 3-phase UPS (without internal battery) with digital signal processing (DSP) control.
