Three-phase UPS Eaton MGE Galaxy PW 160 kVA offering centralized protection of the highest quality with double-conversion topology and high energy efficiency.
Contact us directly on WhatsApp to get the latest live rates & discounts.
Three-phase UPS Eaton MGE Galaxy PW 160 kVA — centralized protection of the highest quality. High energy quality ensures the operation of protected equipment with maximum efficiency, suitable for the protection of 30 to 300 workstations. Thanks to its double-conversion topology, high short-circuit and peak current resistance, and output voltage stability under large and highly nonlinear loads, the Galaxy PW UPS provides optimal and consistent high-quality power supply. Features an improved battery management system (DigiBat™) to optimize charging, calculate real-time runtime, and extend lifespan.
DigiBat™ advanced battery monitoring system for automated testing and extended lifespan.
TNM active filter providing a power factor > 0.95 and reducing current distortion ($THD < 4\%$).
Modular parallel connection capability for up to 4 units (redundancy and scaling).
Comprehensive communication support including SNMP/Web slots and Jbus/Modbus integration.
High-performance 30kVA / 24kW true online double-conversion 3-phase UPS with internal battery and digital signal processing (DSP) control.
| Manufacturer | MGE |
|---|---|
| Net Weight (without packaging | 1200 kg |
| UPS Power | 160 kVA (128 kW) |
| Nominal Voltage | 380-400-415 V ± 15% (Three phases) |
| Frequency | 50/60 Hz ± 10% |
| Topology | Double conversion (VFI complies with EN50091) |
| Efficiency (Double conversion mode) | 93% |
| Efficiency (Economic mode) | 97% |
| Operating Temperature | 0…+35 °C |
High-performance 40kVA / 32kW true online double-conversion 3-phase UPS with internal battery and digital signal processing (DSP) control.
High-performance 60kVA / 48kW true online double-conversion 3-phase UPS (without internal battery) with digital signal processing (DSP) control.
